Compact HMI panels from 5″ to 21,5″, IP66/NEMA4X when panel-mounted.
%20rotate(-45)'/%3e%3c/g%3e%3c/g%3e%3c/g%3e%3c/svg%3e)
USLUniStream Light HMI panel0505″ touchB05EditionUnsure about the type? Get personal advice on +45 70 22 00 66.
| Family | UniStream |
|---|---|
| Display | 5″–21,5″ touch |
| I/O | HMI panel |
| Selected variant | USL-050-B05 – 5″ |
| CPU | HMI |
| Communication | Ethernet, USB, Modbus TCP |
| Power supply | 24 VDC |
| Software | UniLogic (free) |
| Product sheet for this type | USL-050-B05 User Guide |
| 5″ | |
| 7″ | |
| 10,1″ | |
| 15,6″ | |
| 21,5″ |
Uni-I/O and Uni-COM snap directly onto the CPU; use an expansion kit for more modules on DIN rail.
Snap-in I/O for UniStream – directly on the CPU or in a local expansion on DIN rail.
Fits: Modular & PLC: snaps directly onto the CPU · Built-in: via local expansion kit
Extra RS232, RS485 and CANbus ports plus EtherCAT master for UniStream.
Fits: Choose module series by controller: CX for built-in, CB and EtherCAT master for PLC without display (USC-B5/B10), standard for modular CPU (CPU-for-Panel)
Move Uni-I/O out onto DIN rail and add more modules than there is room for on the controller.
Fits: UAG-CX for built-in · UAG-XK for modular & PLC
Spare fronts for UniStream built-in and modular HMI panels – with or without Unitronics logo.
Fits: UniStream built-in 5″/7″ and modular HMI panels
