All UniStream models
UNISTREAM · 17 VARIANTS
Uni-I/O™ modules
Snap-in I/O for UniStream – directly on the CPU or in a local expansion on DIN rail.
- Snap-in mounting
- Automatic detection in UniLogic
Your part number · UID-1600
UIDUni-I/O digital160016 digital inputs1Choose module
Digital (UID)R = relay · T = transistor · W = wide module
Analogue (UIA)
Temperature and special (UIS)
How to read the part number
- UID / UIA / UIS
- Digital / analogue / special and temperature module.
- First 2 digits
- Number of inputs (e.g. 08 = 8 in).
- Last 2 digits
- Number of outputs (e.g. 16 = 16 out).
- R / T
- Relay / transistor outputs.
- W
- Wide module with more channels.
Unsure about the type? Get personal advice on +45 70 22 00 66.
Technical specifications
| Family | UniStream |
|---|---|
| Type | Digital, analogue and temperature |
| Fits | Modular & PLC: snaps directly onto the CPU · Built-in: via local expansion kit |
| Selected variant | UID-1600 – 16 digital inputs |
| Communication | UniStream bus |
| Power supply | Via CPU / 24 VDC |
| Software | UniLogic (free) |
| Product sheet for this type | UID-1600 User Guide |
Documents for Uni-I/O™ modules
- Product sheet · UID-1600 User Guide
- Product sheet · UID-W1616R User Guide
- Product sheet · UIA-0006 User Guide
- Product sheet · UIA-0800N User Guide
- Product sheet · UIA-0800NH User Guide
- Product sheet · UIA-0402N User Guide
- Product sheet · UIS-04PTN User Guide
- Product sheet · UIS-08TC User Guide
- Product sheet · UG_UIS-WCB1 User Guide
- Product sheet · UIS-WCB2 User Guide
All types in Uni-I/O™ modules (17)
| 16 digital inputs | |
| 16 transistor outputs · Transistor | |
| 8 DI, 8 relay · Relay | |
| 8 DI, 8 transistor · Transistor | |
| 16 relay · Relay | |
| 8 DI, 8 high-speed transistor · Transistor | |
| 16 DI, 16 relay (wide) · Relay | |
| 16 DI, 16 transistor (wide) · Transistor | |
| 6 AO | |
| 8 AI | |
| 8 AI, high resolution | |
| 4 AI, 2 AO | |
| 4 PT100/temperature | |
| 4 PT1000/NI1000 | |
| 8 thermocouples | |
| Wide combo: 10 DI (2 HSC), 2 AI, 2 temperature (RTD/TC), 8 relay, 2 transistor (npn, 2 PWM), 2 AO · Relay + transistor | |
| Wide combo: 10 DI (2 HSC), 2 AI, 2 temperature (RTD/TC), 10 transistor (2 PWM), 2 AO · Transistor |
