UNISTREAM · 17 VARIANTS

Local expansion kit

Move Uni-I/O out onto DIN rail and add more modules than there is room for on the controller.

Your part number · UAG-CX-XKP125

UAG-CXExpansion kit for built-in

XKPWith power supply

1251,25 m

LengthThe number = length in cm

How to read the part number

CX: For UniStream built-in (plugs into the I/O expansion port). Without CX = UniStream modular HMI or PLC.
XK / XKP / XKPL: Without power supply (powered by the controller) / with built-in power supply / long range with built-in power supply.
The number: Cable length in cm (125 = 1,25 m, 3000 = 30 m).

Unsure about the type? Get personal advice on +45 70 22 00 66.

Technical specifications

Family	UniStream
Type	Uni-I/O expansion
Fits	UAG-CX for built-in · UAG-XK for modular & PLC
Selected variant	UAG-CX-XKP125 – Built-in · cable 1,25 m with supply
Communication	UniStream bus
Power supply	P kit with power supply for the modules
Software	UniLogic (free)
Product sheet for this type	UAG-CX-XKP125 User Guide

All types in Local expansion kit (17)

	Built-in · cable 1,25 m with power supply
	Built-in · cable 3 m with power supply
	Modular/PLC · cable 1,25 m
	Modular/PLC · cable 3 m
	Modular/PLC · cable 1,25 m with power supply
	Modular/PLC · cable 3 m with power supply
	Modular/PLC · long cable 6 m, external power supply
	Modular/PLC · long cable 12 m, external power supply
	Modular/PLC · long cable 15 m, external power supply
	Modular/PLC · long cable 20 m, external power supply
	Modular/PLC · long cable 30 m, external power supply
	Built-in · long kit 6 m with power supply
	Built-in · long kit 12 m with power supply
	Built-in · long kit 15 m with power supply
	Built-in · long kit 20 m with power supply
	Built-in · long kit 30 m with power supply
	Rear I/O adapter for UniStream 15,6″ (US15)
