MATCHING ACCESSORIES
SERVO · 20 VARIANTS
Servo motors B6 (UMM)
Medium-inertia servo motors 850 W–7,5 kW for heavier axes, with 23-bit absolute encoder.
- 23-bit absolute encoder
- With or without holding brake
- Used with UMD B5/E5 drives
Your part number · UMM-0008CA-B6
UMMUnitronics servomotor0008850 WC200–240 V 3-phaseAAbsolute encoder, 23-bitB6B6 series · medium inertia1Choose voltage
2Choose encoder and brake
3Choose motor power
Motor power4 digits = power code
How to read the part number
- UMM
- Unitronics servomotor.
- 4 digits
- Power: 0008 = 850 W, 0013 = 1,3 kW, 0018 = 1,8 kW, 0029 = 2,9 kW, 0044 = 4,4 kW, 0055 = 5,5 kW, 0075 = 7,5 kW.
- C / E
- 200–240 V 3-phase / 380–480 V 3-phase.
- A / AB
- Absolute encoder (23-bit) without / with holding brake.
- B6
- B6 series: medium inertia, 850 W–7,5 kW.
Unsure about the type? Get personal advice on +45 70 22 00 66.
Technical specifications
| Family | Servo |
|---|---|
| I/O | 850 W–7,5 kW |
| Selected variant | UMM-0008CA-B6 – 850 W, 200 V, 23-bit absolute encoder, without brake |
| Communication | CANopen, EtherCAT |
| Power supply | 200 V or 400 V |
| Software | UniLogic (free) |
Documents for Servo motors B6 (UMM)
All types in Servo motors B6 (UMM) (20)
| 850 W, 200 V, 23-bit absolute encoder, without brake | |
| 1,3 kW, 200 V, 23-bit absolute encoder, without brake | |
| 1,8 kW, 200 V, 23-bit absolute encoder, without brake | |
| 850 W, 200 V, 23-bit absolute encoder, with holding brake | |
| 1,3 kW, 200 V, 23-bit absolute encoder, with holding brake | |
| 1,8 kW, 200 V, 23-bit absolute encoder, with holding brake | |
| 850 W, 400 V, 23-bit absolute encoder, without brake | |
| 1,3 kW, 400 V, 23-bit absolute encoder, without brake | |
| 1,8 kW, 400 V, 23-bit absolute encoder, without brake | |
| 2,9 kW, 400 V, 23-bit absolute encoder, without brake | |
| 4,4 kW, 400 V, 23-bit absolute encoder, without brake | |
| 5,5 kW, 400 V, 23-bit absolute encoder, without brake | |
| 7,5 kW, 400 V, 23-bit absolute encoder, without brake | |
| 850 W, 400 V, 23-bit absolute encoder, with holding brake | |
| 1,3 kW, 400 V, 23-bit absolute encoder, with holding brake | |
| 1,8 kW, 400 V, 23-bit absolute encoder, with holding brake | |
| 2,9 kW, 400 V, 23-bit absolute encoder, with holding brake | |
| 4,4 kW, 400 V, 23-bit absolute encoder, with holding brake | |
| 5,5 kW, 400 V, 23-bit absolute encoder, with holding brake | |
| 7,5 kW, 400 V, 23-bit absolute encoder, with holding brake |
Expand Servo motors B6 (UMM)
