MATCHING ACCESSORIES
SERVO · 28 VARIANTS
Servo drives B5/E5-S (UMD)
Servo drives for the B5 and B6 motors: CANopen (B5) or EtherCAT with Safe Torque Off (E5-S). Choose the drive by the motor’s power.
- B5: CANopen
- E5-S: EtherCAT with built-in STO
- Auto-tuning from UniLogic
- Matched with UMM motors of the same power
Your part number · UMD-0000B-B5
UMDUnitronics servo drive000050 WB200–240 V single-phaseB5CANopen1Choose fieldbus
2Choose power supply
3Choose power
Power4 digits = power code
How to read the part number
- UMD
- Unitronics servo drive.
- 4 digits
- Power: 0000 = 50 W, 0001 = 100 W, 0002 = 200 W, 0004 = 400 W, 0007 = 750 W, 0010 = 1 kW, 0015 = 1,5 kW, 0020 = 2 kW, 0030 = 3 kW, 0050 = 5 kW, 0075 = 7,5 kW.
- B / CU / C / E
- 200–240 V single-phase / 200–240 V single- or 3-phase / 200–240 V 3-phase / 380–480 V 3-phase.
- B5 / E5-S
- CANopen / EtherCAT with Safe Torque Off (STO).
Unsure about the type? Get personal advice on +45 70 22 00 66.
Technical specifications
| Family | Servo |
|---|---|
| I/O | 50 W–7,5 kW |
| Selected variant | UMD-0000B-B5 – Servo drive 50 W, 200 V single-phase, CANopen |
| Communication | CANopen, EtherCAT |
| Power supply | 200 V single/3-phase · 400 V 3-phase |
| Software | UniLogic (free) |
Documents for Servo drives B5/E5-S (UMD)
All types in Servo drives B5/E5-S (UMD) (28)
| Servo drive 50 W, 200 V single-phase, CANopen | |
| Servo drive 100 W, 200 V single-phase, CANopen | |
| Servo drive 200 W, 200 V single-phase, CANopen | |
| Servo drive 400 W, 200 V single-phase, CANopen | |
| Servo drive 750 W, 200 V single/3-phase, CANopen | |
| Servo drive 1 kW, 200 V single/3-phase, CANopen | |
| Servo drive 1,5 kW, 200 V single/3-phase, CANopen | |
| Servo drive 2 kW, 200 V 3-phase, CANopen | |
| Servo drive 1 kW, 400 V 3-phase, CANopen | |
| Servo drive 1,5 kW, 400 V 3-phase, CANopen | |
| Servo drive 2 kW, 400 V 3-phase, CANopen | |
| Servo drive 3 kW, 400 V 3-phase, CANopen | |
| Servo drive 5 kW, 400 V 3-phase, CANopen | |
| Servo drive 7,5 kW, 400 V 3-phase, CANopen | |
| Servo drive 50 W, 200 V single-phase, EtherCAT + STO | |
| Servo drive 100 W, 200 V single-phase, EtherCAT + STO | |
| Servo drive 200 W, 200 V single-phase, EtherCAT + STO | |
| Servo drive 400 W, 200 V single-phase, EtherCAT + STO | |
| Servo drive 750 W, 200 V single/3-phase, EtherCAT + STO | |
| Servo drive 1 kW, 200 V single/3-phase, EtherCAT + STO | |
| Servo drive 1,5 kW, 200 V single/3-phase, EtherCAT + STO | |
| Servo drive 2 kW, 200 V 3-phase, EtherCAT + STO | |
| Servo drive 1 kW, 400 V 3-phase, EtherCAT + STO | |
| Servo drive 1,5 kW, 400 V 3-phase, EtherCAT + STO | |
| Servo drive 2 kW, 400 V 3-phase, EtherCAT + STO | |
| Servo drive 3 kW, 400 V 3-phase, EtherCAT + STO | |
| Servo drive 5 kW, 400 V 3-phase, EtherCAT + STO | |
| Servo drive 7,5 kW, 400 V 3-phase, EtherCAT + STO |
Expand Servo drives B5/E5-S (UMD)
