SERVO · 60 VARIANTS
Servo motors B2/B3/B4 (UMM)
Servo motors B2, B3 and B4 for UMD B3/E3 drives.
- For UMD B3/E3 drives
- Absolute (23-bit) or incremental (20-bit) encoder
- With or without holding brake
Your part number · UMM-0000BA-B4
UMMUnitronics servomotor000050 WB200 VAAbsolute encoder, 23-bitB4B4 series (previous)1Choose motor series
2Choose voltage
3Choose encoder and brake
4Choose motor power
Motor power4 digits = power code
How to read the part number
- UMM
- Unitronics servomotor.
- 4 digits
- Power: 0000 = 50 W, 0001 = 100 W, 0002 = 200 W, 0004 = 400 W, 0007 = 750 W, 0010 = 1 kW, 0015 = 1,5 kW, 0020 = 2 kW, 0030 = 3 kW, 0050 = 5 kW.
- B / C / E
- Voltage class: B and C = 200 V, E = 400 V.
- A / AB / N / NB
- Absolute (23-bit) / incremental (20-bit) encoder, without or with holding brake (B).
- B2 / B3 / B4
- Motor series in the previous servo series.
Unsure about the type? Get personal advice on +45 70 22 00 66.
Technical specifications
| Family | Servo |
|---|---|
| I/O | 50 W–5 kW |
| Selected variant | UMM-0000BA-B4 – Motor B4: 50 W, 200 V, 23-bit absolute encoder, without brake |
| Communication | CANopen, EtherCAT |
| Power supply | 200 V or 400 V |
| Software | UniLogic (free) |
All types in Servo motors B2/B3/B4 (UMM) (60)
| Motor B4: 50 W, 200 V, 23-bit absolute encoder, without brake | |
| Motor B4: 50 W, 200 V, 23-bit absolute encoder, with holding brake | |
| Motor B4: 100 W, 200 V, 23-bit absolute encoder, without brake | |
| Motor B4: 100 W, 200 V, 23-bit absolute encoder, with holding brake | |
| Motor B4: 200 W, 200 V, 23-bit absolute encoder, without brake | |
| Motor B4: 200 W, 200 V, 23-bit absolute encoder, with holding brake | |
| Motor B4: 200 W, 200 V, 20-bit incremental encoder, without brake | |
| Motor B4: 200 W, 200 V, 20-bit incremental encoder, with holding brake | |
| Motor B4: 400 W, 200 V, 23-bit absolute encoder, without brake | |
| Motor B4: 400 W, 200 V, 23-bit absolute encoder, with holding brake | |
| Motor B4: 400 W, 200 V, 20-bit incremental encoder, without brake | |
| Motor B4: 400 W, 200 V, 20-bit incremental encoder, with holding brake | |
| Motor B4: 750 W, 200 V, 23-bit absolute encoder, without brake | |
| Motor B4: 750 W, 200 V, 23-bit absolute encoder, with holding brake | |
| Motor B4: 750 W, 200 V, 20-bit incremental encoder, without brake | |
| Motor B4: 750 W, 200 V, 20-bit incremental encoder, with holding brake | |
| Motor B4: 1 kW, 200 V, 23-bit absolute encoder, without brake | |
| Motor B4: 1 kW, 200 V, 23-bit absolute encoder, with holding brake | |
| Motor B4: 1 kW, 200 V, 20-bit incremental encoder, without brake | |
| Motor B4: 1 kW, 200 V, 20-bit incremental encoder, with holding brake | |
| Motor B2: 1,5 kW, 200 V, 23-bit absolute encoder, without brake | |
| Motor B2: 1,5 kW, 200 V, 23-bit absolute encoder, with holding brake | |
| Motor B2: 1,5 kW, 200 V, 20-bit incremental encoder, without brake | |
| Motor B2: 1,5 kW, 200 V, 20-bit incremental encoder, with holding brake | |
| Motor B2: 2 kW, 200 V, 23-bit absolute encoder, without brake | |
| Motor B2: 2 kW, 200 V, 23-bit absolute encoder, with holding brake | |
| Motor B2: 2 kW, 200 V, 20-bit incremental encoder, without brake | |
| Motor B2: 2 kW, 200 V, 20-bit incremental encoder, with holding brake | |
| Motor B3: 3 kW, 200 V, 23-bit absolute encoder, without brake | |
| Motor B3: 3 kW, 200 V, 23-bit absolute encoder, with holding brake | |
| Motor B3: 3 kW, 200 V, 20-bit incremental encoder, without brake | |
| Motor B3: 3 kW, 200 V, 20-bit incremental encoder, with holding brake | |
| Motor B3: 5 kW, 200 V, 23-bit absolute encoder, without brake | |
| Motor B3: 5 kW, 200 V, 23-bit absolute encoder, with holding brake | |
| Motor B3: 5 kW, 200 V, 20-bit incremental encoder, without brake | |
| Motor B3: 5 kW, 200 V, 20-bit incremental encoder, with holding brake | |
| Motor B2: 1 kW, 400 V, 23-bit absolute encoder, without brake | |
| Motor B2: 1 kW, 200 V, 23-bit absolute encoder, without brake | |
| Motor B2: 1 kW, 400 V, 23-bit absolute encoder, with holding brake | |
| Motor B2: 1 kW, 200 V, 23-bit absolute encoder, with holding brake | |
| Motor B2: 1 kW, 400 V, 20-bit incremental encoder, without brake | |
| Motor B2: 1 kW, 200 V, 20-bit incremental encoder, without brake | |
| Motor B2: 1 kW, 400 V, 20-bit incremental encoder, with holding brake | |
| Motor B2: 1 kW, 200 V, 20-bit incremental encoder, with holding brake | |
| Motor B2: 1,5 kW, 400 V, 23-bit absolute encoder, without brake | |
| Motor B2: 1,5 kW, 400 V, 23-bit absolute encoder, with holding brake | |
| Motor B2: 1,5 kW, 400 V, 20-bit incremental encoder, without brake | |
| Motor B2: 1,5 kW, 400 V, 20-bit incremental encoder, with holding brake | |
| Motor B2: 2 kW, 400 V, 23-bit absolute encoder, without brake | |
| Motor B2: 2 kW, 400 V, 23-bit absolute encoder, with holding brake | |
| Motor B2: 2 kW, 400 V, 20-bit incremental encoder, without brake | |
| Motor B2: 2 kW, 400 V, 20-bit incremental encoder, with holding brake | |
| Motor B3: 3 kW, 400 V, 23-bit absolute encoder, without brake | |
| Motor B3: 3 kW, 400 V, 23-bit absolute encoder, with holding brake | |
| Motor B3: 3 kW, 400 V, 20-bit incremental encoder, without brake | |
| Motor B3: 3 kW, 400 V, 20-bit incremental encoder, with holding brake | |
| Motor B3: 5 kW, 400 V, 23-bit absolute encoder, without brake | |
| Motor B3: 5 kW, 400 V, 23-bit absolute encoder, with holding brake | |
| Motor B3: 5 kW, 400 V, 20-bit incremental encoder, without brake | |
| Motor B3: 5 kW, 400 V, 20-bit incremental encoder, with holding brake |
