SENSORS · 9 VARIANTS

IO-Link Master

Connect IO-Link sensors and actuators to the controller.

Your part number · ULK-EIP-8AP6

ULKUnitronics IO-Link

EIP-8AP6Master, 8 × class A, EtherNet/IP, IP67

IO-Link mastersConnects to the PLC via EtherNet/IP

IO-Link hubsConnects to a master port

How to read the part number

EIP: EtherNet/IP-master.
4A / 8A / 4A4B: Number of class A and class B ports (B = extra actuator supply).
1616 / 0808: Number of I/O points on the hub (16 or 8).
P / AIO: PNP digital I/O / analogue I/O.
M2 / M8: M12 or M8 connector.
P6: IP67.

Unsure about the type? Get personal advice on +45 70 22 00 66.

Technical specifications

Family	Sensors
I/O	8 IO-Link ports, IP67
Selected variant	ULK-EIP-8AP6 – Master, 8 × class A, EtherNet/IP, IP67
Communication	EtherNet/IP, IO-Link
Power supply	24 VDC
Software	Model-dependent (free)
Product sheet for this type	IO-LINK Master: ULK-EIP-8AP6 - User Guide

All types in IO-Link Master (9)

	Master, 8 × class A, EtherNet/IP, IP67
	Master, 4 × class A, EtherNet/IP, IP67
	Master, 4 × class A + 4 × class B, EtherNet/IP, IP67
	Hub, 16 I/O PNP, M12
	Hub, 16 I/O PNP, class A port, M12
	Hub, 8 I/O PNP, M8
	Hub, 8 I/O NPN, M8
	Hub, 16 I/O NPN, M12
	Hub, 8 analogue I/O, M12

MATCHING ACCESSORIES

ACCESSORIES · 31 VARIANTS Unitronics IO-Link cables and adapters

M8/M12 cables, Y-splitters and configuration adapter for IO-Link.

Fits: IO-Link masters and hubs (ULK)

ADP-M12AM4-2M12F4ADP-M12AM4-2M8F3ADP-ULKCFG+28
